| Stamping | CRNO |
|---|---|
| Impeller | ALUMINIUM/C.l. |
| Bowl | C.l. |
| Shaft | EN-8 |
| Bearing Bush | Gun Metal |
Application
| Types of Fluids | Water | Cooling Emulsion | Cooling / Cutting Oil |
|---|---|
| Pumping Temperature | 0-80C |
Used On
All CNC Machines, Lathes and Machining Centers, Most Suitable for Through Tool Cooling, Deep Hole Drilling etc. Also suitable for industrial washing.
Cooling Motor Detail Dimensions
| Type | No.Of Stage | H1 Immersion Depth | H2 | D | L1 | L2 | d1 BSP | E | PCD | Power in KW/HP | Weight In KG. |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CEC-115 | 1 | 195/245/295 | 245 | 122 | 100 | 95 | G1″ | 30 | 160 | 0.30/0.50 | 12 |
| CEC-120 | 2 | 215/265/315 | 245 | 122 | 100 | 95 | G1″ | 30 | 60 | 0.7/0.75 | 14 |
| CEC-252 | 2 | 205 | 254 | 140 | 110 | 95 | G1 1/4″ | 30 | 160 | 1.1/1.5 | 19 |
| CEC-130 | 3 | 230 | 254 | 140 | 110 | 95 | G1″ | 30 | 160 | 0.9/1.25 | 19 |
| CEC-253 | 3 | 260 | 315 | 177 | 135 | 95 | G1 1/4″ | 30 | 160 | 1.5/2 | 30 |
| CEC-254 | 4 | 310 | 340 | 177 | 135 | 95 | G1 1/4″ | 30 | 160 | 1.7/2.3 | 36 |
| CEC-402 | 2 | 370 | 430 | 195 | 140 | 125 | G1 1/2″ | 42 | 225 | 2.95/4 | 57 |
| CEC-602 | 2 | 380 | 430 | 195 | 140 | 125 | G2″ | 42 | 225 | 4/5.5 | 59 |
